Brannan 50mm (2") 0-6 bar Black Steel Case Pressure Gauge (Back Entry)
In stock
Product Code
U93652
50mm Pressure Gauge 0 to 6 bar & psi
Applications
· Suitable for gaseous and liquid media that will not obstruct the pressure system or attack copper alloy parts.
· Pneumatics and hydraulics
· Heating, ventilation, air-conditioning
Standard Product Specifications
Design: BS EN 837
Accuracy Class: 2.5
Case: 50mm, Black Steel
Connection: 1/4” BSP Brass Bottom or Back Entry
Window: Clear Plastic, snap fit
Pointer: Black aluminium
Filling: Dry
Working Pressure: Steady: 75% full scale range
Fluctuating: 60% full scale range
Short Time: full scale range
Operating Temperature: Ambient: -20 to +60°C
Medium: -20 to +60°C
Storage Temperature: -40 to +60°C
Temperature Effect: When temperature of the pressure element deviates from reference temperature of 20°C the maximum additional error is +/- 0.4% per 10°C of the span rising and falling.
Applications
· Suitable for gaseous and liquid media that will not obstruct the pressure system or attack copper alloy parts.
· Pneumatics and hydraulics
· Heating, ventilation, air-conditioning
Standard Product Specifications
Design: BS EN 837
Accuracy Class: 2.5
Case: 50mm, Black Steel
Connection: 1/4” BSP Brass Bottom or Back Entry
Window: Clear Plastic, snap fit
Pointer: Black aluminium
Filling: Dry
Working Pressure: Steady: 75% full scale range
Fluctuating: 60% full scale range
Short Time: full scale range
Operating Temperature: Ambient: -20 to +60°C
Medium: -20 to +60°C
Storage Temperature: -40 to +60°C
Temperature Effect: When temperature of the pressure element deviates from reference temperature of 20°C the maximum additional error is +/- 0.4% per 10°C of the span rising and falling.
| Brand | Brannan |
|---|---|
| Manufacturer Part Code | 34/145/0 |
| Product Type | Gauge |
| Pressure | 0 - 6 bar |
| Standards | BS EN 837 |
| Diameter | 50 mm |
| Connection Type | Back Entry |
| Connection Size | ¼" BSP |
